Safe and easy to use, Permatex® BullseyeTM Windshield Repair uses an advanced system to repair damage caused by stone impact.
Using the same resin and method that windshield repair professionals rely on, Bullseye® Repair may be used on stars and bullseyes up to 1-1/4″ in diameter to prevent further spreading of glass fractures, allowing you to avoid costly windshield replacement.
NOTE: While this product will repair damaged area and prevent spreading when applied according to instructions, a shadow of the original damage may still be visible after use and cure.
INSTRUCTIONS
See corresponding photos on flip side
1. CLEAN out any loose glass
particles from PIT (hole caused by
striking object) of the break using
push pin. Clean the area surrounding
the break using a dry cloth or paper
towel.
2. PEEL backing off ONE side of
adhesive seal. Line up hole in seal
with PIT (tab pointing upward). Press
seal to glass. Run fingers around seal
to insure a tight bond.
3. PEEL backing from TOP side of
adhesive.
4. Line up the pedestal with the
adhesive seal making sure tabs
match up. Press the pedestal to
seal. Run fingers around pedestal to
insure a tight bond.
5. Cut tip off resin container (about
1/8 inch) to open stem. Place stem
1/4 inch into pedestal opening.
Slowly squeeze resin tube, releasing
resin into the pedestal. Continue
squeezing resin tube and remove
from pedestal. Wipe any excess resin
from tip with cloth and SAVE empty
container for Step 10.
6. Press fit INJECTOR into pedestal.
Insure that the connection is tight.
7. Hold injector in one hand, pull
plunger upward with other hand.
LOCK plunger by ENGAGING LOWER
notch in plunger with spring clip.
Release hands and allow device to
remain in locked position. LET SIT
FOR 10 MINUTES then proceed to
Step 8.
8. Remove injector from pedestal
momentarily (to let air in). Replace
injector as in Step 6. DEPRESS
plunger downward and ENGAGE
UPPER notch with spring clip.
LET SIT FOR A MINIMUM OF 20
MINUTES then proceed to Step 9.
9. Remove injector and discard.
Loosen the outer edges of pedestal
with safety razor. Once top part of
pedestal and seal is bent away from
the glass, grip the pedestal tab as
shown. SLOWLY pull tab away.
WIPE and remove excess resin.
10. Hold resin container in one hand
and make ready the clear curing film
in the other hand (as shown). Slowly
squeeze the resin container applying
a drop of resin in PIT. Place clear
curing film over PIT holding resin in
the PIT.
11. Run safety razor lightly over
clear film to vent out any air bubbles.
Note: Ultra violet sun rays cure the
resin. Park vehicle in direct sunlight
for 15 minutes. (On hazy days park
vehicle in sunlight for a minimum of
1 hour).
NOTE: The repair may not
completely remove blemish or
permanently fill the pit.
Permatex Bullseye Windshield Repair Kit is the first one-component windshield repair system designed to be used by the car owner. Can be used to make air-tight repairs of bullseye damage up to 1 1/4″ in diameter on most laminated windshield glass. This all-in-one kit is safe and easy to use and requires no mixing, no heat, making the repair virtually undetectable.
